Ideal for work on small to medium plots.

This range of tillers offers great cultivation performance and are easy to store.

Our mini range breaks up tough soil and ensures it is in the best condition. These tillers work equally as well at clearing weeds from between rows of plants to ensure your plots are at their best.

Product Overview:

Max tilling width (mm): 545

Max tilling depth (mm): 280

Wheels: Front transport

Side Discs: Yes

Foldable Handle: Yes

Height Adjustment Handle: Yes

Swing Handle: Yes

Counter-rotating tines: Not available

Unrivalled warranty

Our products are built better to last longer. That's why we can offer you a rock-solid warranty for domestic and professional use on our core range products, covering both parts and labour. The warranty also maintains the same value throughout the warranty period - meaning the last day of cover is exactly the same as the first.

*Subject to domestic use and following the service schedule

Function

Max tilling width (mm) 545

Max tilling depth (mm) 280

Forward speeds 1

Forward tool rotation speed (rpm) 130 rpm

Dimensions

Dimension (L x W x H) (mm) 1,280 x 615 x 1,035

Dry weight (kg) 30

ACC

Rotors/tines supplied 4 x 4 tooth digging tines

Wheels Front Transport

Side discs Yes

De-thatcher / scarifier Optional

Ridger Optional

Engine

Engine 4-stroke OHC

Engine model GXV57

Engine displacement (cc) 57.3

Engine net power (kW/rpm) 1.5/4,800

Fuel tank capacity (Litres) 0.7

Engine oil capacity (Litres) 0.3

Starter Recoil

Drive clutch Manual - centrifugal

Transmission Epicyclic gearing

Final transmission Pinion & bevel gear

Sound pressure at operators ears (dB(A)) 75

Guaranteed sound power level (dB(A)) 92

Vibration (m/sec²) 6.4

Handle

Foldable handle Yes

Height adjustable handle Yes

Swing handle Yes
